McKinney TA786 NRP Heavy Weight Hinge | 5" x 4-1/2" Satin Chrome
The McKinney TA786 NRP is a high-performance heavy weight concealed bearing hinge specifically engineered for high-traffic commercial applications. Featuring a streamlined 3-knuckle, full mortise profile and a robust .190 gauge thickness, this hinge is the ultimate solution for door restoration on heavy wood or metal doors. Finished in professional US26D Satin Chrome, it combines a modern architectural aesthetic with advanced security features for demanding institutional environments.
High-Security NRP (Non-Removable Pin)
The NRP (Non-Removable Pin) feature is a critical security innovation for modern facility management. It utilizes a hidden set screw driven into the hinge barrel that is completely inaccessible when the door is closed.
- Anti-Tamper Protection: Prevents unauthorized removal of the door by ensuring the pin cannot be tapped out from the exterior.
- Essential for Outward Swinging Doors: Provides a vital solution for commercial door security on exterior-facing doors where hinge barrels are exposed.
- Forced Entry Prevention: Safeguards against intruders attempting to bypass locking hardware through hinge manipulation.
Advanced Concealed Bearing Technology (TA Prefix)
The TA Prefix signifies McKinney’s sophisticated twin anti-friction bearing system, providing a smooth swing without the bulky appearance of traditional 5-knuckle styles:
- Concealed Vertical & Lateral Thrust: Dual internal bearings manage heavy door weights and lateral forces, ensuring silent and effortless operation.
- Modern 3-Knuckle Aesthetic: By hiding the bearings, this hinge offers a continuous, elegant line that is easier to clean and maintain in medical or office settings.
- Heavy Weight .190 Gauge: Built with industrial-grade steel to support oversized doors and withstand frequent daily cycles without sagging or failure.
Technical Details & Specifications
- Brand: McKinney (ASSA ABLOY)
- Model: TA786 NRP
- Dimensions: 5" Height x 4-1/2" Width (Heavy Weight .190 Gauge)
- Finish: US26D (626) Satin Chrome plated steel.
- ANSI/BHMA Standards: Complies with ANSI A8111 for quality and performance.
- Non-Rising Flush Pin: Features a steel pin that stays flush with the barrel to maintain a minimalist look and prevent upward migration.
- Fasteners Included: Furnished with all Wood Screws (1-1/4" x 12 FPHW) and all Machine Screws (1/2" x 12-24 FPHM).
Why Choose the McKinney TA786 NRP?
The McKinney TA786 NRP is the definitive professional choice for projects requiring "Grade 1" durability and high-level security. Whether you are performing a solution for door surface repair or outfitting a new commercial office tower, its combination of heavy-weight steel and concealed bearing technology ensures unmatched longevity.
| General - US Finishes | US26D - Satin Chrome |
| Brand | McKinney |
| Hinge Height | 5.0" Hi |
| Hinge Width | 4.5" Wi |
| Hinge Grade/Thickness | Heavy Wt .180 to .190 |
| Hinge Type | Full Mortise |
| Hinge Options | Concealed Bearing, NRP (Non Removable Pin) |
| Base Material | Steel |
| Hinge Corners | Square |
