McKinney TA714 Concealed Bearing Hinge | 5" x 4-1/2" 3-Knuckle Steel Hinge
The McKinney TA714 is a high-performance, full-mortise architectural hinge designed for modern commercial construction. Featuring a sleek 3-knuckle design and advanced concealed bearings, this hinge provides a clean, streamlined aesthetic without sacrificing the weight-bearing capabilities required for average-traffic openings. It serves as an ideal solution for door restoration, offering a sophisticated, high-end look for offices, hospitality suites, and retail environments that require a larger 5" hinge height.
Engineered with vertical and lateral thrust twin anti-friction bearings at both joints, the TA714 ensures a lifetime of smooth, silent operation. These bearings are completely concealed within the knuckles, protecting them from dust and contaminants while providing a tamper-resistant solution for commercial door security. This hinge is a vital component for any solution for door surface repair, as its standard template screw hole pattern and .146 gauge thickness allow for the seamless replacement of worn hardware on existing metal or wood doors.
Key Features & Performance
- Concealed Anti-Friction Bearings: Features twin bearings hidden within the joints to manage thrust loads, acting as a permanent solution for door edge reinforcement.
- Modern 3-Knuckle Design: Provides a contemporary, architectural appearance with a flush pin and non-rising steel pin construction for a seamless profile.
- Commercial Grade Durability: Built with a robust .146 gauge thickness, this hinge is precision-engineered for average-traffic commercial facilities.
- Satin Chrome Finish (US26D): The high-quality plated finish acts as a protective remodeling scar plate, resisting corrosion and daily wear while matching standard commercial hardware.
- Large Format Sizing: The 5" x 4-1/2" dimensions are ideal for taller or wider doors that require additional leaf height for stability and weight distribution.
Technical Details & Specifications
- Brand: McKinney (ASSA ABLOY)
- Model Number: TA714
- Dimensions: 5" Height x 4-1/2" Width (Full Mortise)
- Finish: US26D (Satin Chrome)
- Bearing Type: Concealed Vertical & Lateral Thrust (TA Prefix)
- Knuckle Count: 3 Knuckle
- Thickness: .146 Gauge
- ANSI Number: A8112
- Fasteners Included: Furnished with All Wood Screws (1-1/4" x 12 FPHW) and All Machine Screws (1/2" x 12-24 FPHM).
Why Choose the McKinney TA714?
The McKinney TA714 is the professional’s choice for projects where aesthetics are as vital as function. While traditional 5-knuckle hinges show visible bearing lines, the concealed bearing technology of the TA714 provides a smooth, unbroken profile that enhances the architectural appeal of the opening. It offers a permanent and cost-effective solution for door security, delivering industrial-grade reliability and a polished, high-end appearance.
| General - US Finishes | US26D - Satin Chrome |
| Brand | McKinney |
| Hinge Height | 5.0" Hi |
| Hinge Width | 4.5" Wi |
| Hinge Grade/Thickness | Standard Wt .119 to .146 |
| Hinge Type | Full Mortise |
| Hinge Options | Concealed Bearing |
| Base Material | Steel |
| Hinge Corners | Square |
